SIZE mm sq.	Type	Pole	Output	Voltage	Frequency	Duty	Rated Load				StartingTorque		Capacitor
			Output	Voltage	Frequency		Current	Speed	Torque		StartingTorque		Capacitor
			(W)	(V)	(Hz)		(A)	(rpm)	(kg-cm)	(N-m)	(kg-cm)	(N-m)	(uF)
80	S8R25GA-E S8R25GA-E(TP) S8R25GA-ECE	4	25	1 ø 110	60	30Min.	0.73	1550	1.62	0.162	2.40	0.240	10.0
	S8R25GB-E S8R25GB-E(TP) S8R25GB-ECE	4	25	1 ø 220	60	30Min.	0.36	1550	1.62	0.162	2.40	0.240	2.5
	S8R25GC-E S8R25GC-E(TP) S8R25GC-ECE	4	25	1 ø 100	50	30Min.	0.60	1250	2.00	0.200	2.20	0.220	10.0
	S8R25GC-E S8R25GC-E(TP) S8R25GC-ECE	4	25	1 ø 100	60	30Min.	0.70	1500	1.70	0.170	2.20	0.220	10.0
	S8R25GD-E S8R25GD-E(TP) S8R25GD-ECE	4	25	1 ø 200	50	30Min.	0.30	1250	2.00	0.200	2.00	0.200	2.5
	S8R25GD-E S8R25GD-E(TP) S8R25GD-ECE	4	25	1 ø 200	60	30Min.	0.35	1500	1.70	0.170	2.00	0.200	2.5
	S8R25GE-E S8R25GE-ECE	4	25	1 ø 100	50	30Min.	0.58	1250	2.00	0.200	1.60	0.160	8.0
				1 ø 100	60		0.54	1550	1.70	0.170	1.60	0.160	8.0
				1 ø 115	60		0.52	1600	1.65	0.165	1.90	0.190	7.0
	S8R25GX-E S8R25GX-ECE	4	25	1 ø 220	50	30Min.	0.25	1250	2.00	0.200	2.10	0.210	2.0
	S8R25GX-E S8R25GX-ECE	4	25	1 ø 240	50	30Min.	0.27	1250	2.10	0.210	2.50	0.250	2.0
	S8I25GU-E S8I25GU-ECE	4	25	3 ø 200	50	Cont.	0.26	1300	1.95	0.195	3.50	0.350	-
	S8I25GU-E S8I25GU-ECE	4	25	3 ø 200	60	Cont.	0.24	1550	1.65	0.165	2.90	0.290	-
	S8I25GT-E S8I25GT-ECE	4	25	3 ø 220	50	Cont.	0.28	1350	1.90	0.190	4.20	0.420	-
	S8I25GT-E S8I25GT-ECE	4	25	3 ø 220	60	Cont.	0.24	1600	1.60	0.160	3.50	0.350	-
	S8I25GS-E S8I25GS-ECE	4	25	3 ø 380	50	Cont.	0.14	1250	2.00	0.200	3.15	0.315	-
				3 ø 380	60	Cont.	0.12	1500	1.70	0.170	2.50	0.250
				3 ø 400	50	Cont.	0.14	1250	2.10	0.210	3.50	0.350
				3 ø 400	60	Cont.	0.12	1500	1.80	0.180	2.75	0.275
				3 ø 415	50	Cont.	0.15	1300	1.95	0.195	3.75	0.375
				3 ø 415	60	Cont.	0.13	1550	1.65	0.165	3.00	0.300
				3 ø 440	50	Cont.	0.15	1300	2.10	0.210	4.40	0.440
				3 ø 440	60	Cont.	0.13	1600	1.60	0.160	3.40	0.340

MODEL	GEAR RATIO	3	3.6	5	6	7.5	9	10	12.5	15	18	20	25	30	36	40	50	60	75	90	100	120	150	180	200
MODEL	RPM	500	416	300	250	200	166	150	120	100	83	75	60	50	41	37	30	25	20	16	15	12	10	8	7.5
S8KA□B	kg-cm	3.4	4.1	5.7	6.8	8.5	10.2	11.3	14.2	17.0	20.4	20.4	25.6	30.7	36.8	40.9	46.2	55.4	69.2	80	80	80	80	80	80
S8KA□B	N-m	0.333	0.402	0.559	0.666	0.833	1.000	1.107	1.392	1.666	1.999	1.999	2.509	3.009	3.606	4.008	4.530	5.433	6.786	7.840	7.840	7.840	7.840	7.840	7.840

MODEL	GEAR RATIO	3	3.6	5	6	7.5	9	10	12.5	15	18	20	25	30	36	40	50	60	75	90	100	120	150	180	200
MODEL	RPM	600	500	360	300	240	200	180	144	120	100	90	72	60	50	45	36	30	24	20	18	15	12	10	9
S8KA□B	kg-cm	2.9	3.5	4.9	5.9	7.3	8.7	9.7	12.2	14.6	17.5	17.5	21.9	26.3	31.5	35.0	39.6	47.5	59.4	71.3	79.2	80	80	80	80
S8KA□B	N-m	0.284	0.343	0.481	0.568	0.715	0.853	0.951	1.196	1.432	1.715	1.715	2.146	2.577	3.087	3.430	3.881	4.658	5.825	6.992	7.767	7.840	7.840	7.840	7.840
